SG28

SG-series is the Next-generation Sinker EDM machine incorporating the Maisart (Mitsubishi Electric’s AI creates the State of the ART in technology) and M800 controller unit (D-CUBES) to pursue both high performance and high productivity.
Automatic depth recognition and stable servo control using “Maisart” make uniform surface finish. The all new M800 D-CUBES controller with 19 inch touch screen is like a smartphone and new thin operation box is a standard equipment for easy operating and programming.
The heart of the SG series is the GV80 generator for maximum performance with minimum wear with graphite electrodes is required in mould making, whether carbide must be economically machined, or even unusual tasks such as the machining of titanium or PCD, the GV generator is ideally equipped for all tasks.
High rigidity construction is realized by structural change of cast and Middle-Large area machining performance is improved (machining time, electrode wear).
With the all new functions to further innovate machining performance.

Send Enquiry Product Brochure Promotion Video Low wear
Specification
Standard Machine Specifications
Machine travel [ X x Y x Z ] (mm) - 650 x 450 x 400
Max. work-piece dimensions [ W x D x H ] (mm) - 1050 x 760 x 350
Max. work-piece weight (Kg) - 2000
Axis movement (-) - Fixed table, Column Movement
Dist. b/w table & electrode mount face (mm) - 280 to 680
Max. electrode weight (Kg) - 200
Unit weight (Kg) - 5600
Initial Dielectric fluid amount (Ltr) - 595
Dielectric fluid chiller unit - In-build unit coller
Method of Working tank door - Automatic elevation tank
Max. machining peak current (A) - 80
Power requirement (kVA) - 7
User memory capacity (GB) - 1
Min. drive unit (µm) - 0.1
C - Axis and Automatic tool changer - Available as option
Features related to Industry 4.0 - Remote 360
